Castings for Hydropower Station

The castings for hydropower station is mainly hydro-turbine blades. For machined surfaces of the castings, 100% area MT and 100% volume UT shall be carried out in accordance with “Specification for Inspection of Steel Castings for Hydraulic Machines” after finishing/grinding. In the actual use the quality of the products has won unanimous praise from the third-party inspection agency and the customers....

  • Main products：
  • Castings for mixed flow hydroturbine
  • Castings for axial flow hydroturbine

  • Application

    Martensitic stainless steel castings (such as runner ,the core component of hydropower equipment, runner crown, band, blade) and duplex stainless steel castings (such as pump casing, pump cover, guide vane) are strictly tested to meet the user's requirements.

Features

Many types of castings used for 110MW~ 360MW hydropower station have been produced. And the quality of the products has reached the international advanced level.



Reference List for Stainless steel Castings used for Hydropower Station

Customer

Product Description

Material Grade

Tianjin Hydropower Equipment Co., Ltd.

Runner, blade

ZG04Cr13Ni4Mo

ZG06Cr13Ni5Mo

ZHEFU Holding Group Co.,Ltd

Runner, blade

ZG04Cr13Ni4Mo

ZG06Cr13Ni5Mo

Dongfang Electric Machinery Co., Ltd

Runner crown, band, blade and guide vane

ZG04Cr13Ni4Mo

ZG04Cr13Ni5Mo

Xiangtan Electric Manufacturing Group

Pump casing, impeller, guide vane

ZG06Cr13Ni4Mo

CD3MN、CF8M、CF3M

EBARA Corporation, Japan

impeller, guide vane

CD3MN、CF8M、CF3M


Certificates

For castings, TYHI has obtained the works approval of CCS (China classification society), LR (Lloyd's Register of Shipping - UK), DNV (Det Norske Veritas - Norway), GL (Germanischer Lloyd - Germany), ABS (American Bureau of Shipping- the USA), BV (Bureau Veritas - France) and KR (Korean Register of Shipping - Korea).
